MDIthane Series

Conventional polyester elastomers have weak water resistance, and they undergo hydrolysis with temperature and water vapor, resulting in the precipitation of acid, which in turn promotes their hydrolysis. MDIthane modifies the material to enhance its water resistance and environmental adaptability at room temperature, with characteristics such as low moisture absorption, permeability, resistance to steam, water, and seawater.

YALIDE > Material Selection>Material Series> MDIthane Series

MDIthane Series

Conventional polyester elastomers have weak water resistance, and they undergo hydrolysis with temperature and water vapor, resulting in the precipitation of acid, which in turn promotes their hydrolysis. MDIthane modifies the material to enhance its water resistance and environmental adaptability at room temperature, with characteristics such as low moisture absorption, permeability, resistance to steam, water, and seawater.
Application

MDIthane is developed on the raw material 4,4 ` - diphenylmethane diisocyanate, which has excellent mechanical and dynamic properties. It has excellent load-bearing capacity, high wear resistance, and outstanding hydrolysis resistance.

Hydrolysis resistance
Chemical resistance
High wear resistance
Oil resistant
Ozone resistant
Vibration absorption

Technical Data

Mechanical property	ISO Standard	Unit	Parameter
Hardness	868	Shore A	75	80	85	90
100%Tensile Modulus	37	MPa	2.3	4.1	5.5	7.7
300%Tensile Modulus	37	MPa	6.3	7.9	11	14
Tensile Strength	37	MPa	33	39	42	51.8
Rebound	34	kN/m	34	77	96	116.5
Elongation at break	37	%	550	509	534	565
Tear Strength	4662	%	46	60	54	58
Abrasion	4649	mm³	48	40	38	38
Taber abrasion (S42/4.9N)	9352	mg	54.72	45.6	43.32	43.32
Permanent compression deformation	815
23°C/70H		%	15	16	16	16
70°C/70H		%	26	28.7	27	27
