AGV wheels

AGV wheels are the core components for its movement and task execution, directly affecting the AGV’s mobility, positioning accuracy, load-bearing capacity, and environmental adaptability. The AGV wheel system usually consists of driving wheels, driven wheels (universal/directional wheels), as well as related motors, reducers, steering mechanisms, and brakes. The AGV drive wheels are responsible for providing power and are the “heart” of the AGV. Usually integrated with servo motors and reducers. AGV driven/carrying wheels mainly serve to support and assist in movement, without power.

AGV wheels Parameters

We provide a comprehensive AGV wheel solution, using low compression deformation polyurethane material to ensure precise traction and excellent wear resistance, achieving smooth and quiet start stop and operation. The design of the universal wheels is flexible and the steering is precise, effectively assisting AGV in completing complex path movements.

Number	Outer diameter (mm)	Width (mm)	Inner diameter (mm)	Single wheel load (kg)
YLD-28×22-10	28	22	10	50
YLD-62.5×25-28	62.5	25	28	100
YLD-77×22-41	77	22	41	400
YLD-90×24-41	90	24	41	400
YLD-100×40-55	100	40	55	800
YLD-130×35/42/52-30	130	35/42/52	30	150
YLD-150×40-50	150	40	50	800
YLD-150×40-55	150	40	55	800
YLD-160×40-95	160	40	95	1000
YLD-160×50-120	160	50	120	1500
YLD-220×40-40	220	40	40	1000
YLD-130×50-106	130	50	106	600
YLD-144×32-95	144	32	95	500
YLD-160×40-38	160	40	38	600
YLD-165×37-93	165	37	93	600
YLD-170×40-63	170	40	63	600
YLD-177×37-93	177	37	93	600
YLD-180×50-35	180	50	35	800
YLD-190×40-20	190	40	20	750
YLD-190×55-120	190	55	120	900
YLD-200×42-115	200	42	115	800
YLD-210×50-40	210	50	40	900
YLD-250×55-35	250	55	35	1000
