Driving wheels

The driving wheel is a key precision transmission component in semiconductor manufacturing equipment, mainly used in high-precision scenarios such as wafer transfer and lithography platform positioning. In the manufacturing process of semiconductors and LCD panels, the core value of polyurethane drive wheels lies not in “rolling”, but in “cleanliness, anti-static, protection, and stability”. So the development of materials for such drive wheels has become extremely important. Additives in ordinary polyurethane may generate particles or release chemical gases (AMC – air molecule pollutants) during friction, contaminating the wafer.

Cleanroom Driving Wheels Parameters

The driving tire surface we produce uses an elastic material developed based on NDI polyurethane. In addition to ensuring its mechanical and dynamic performance during operation, it also has the characteristic of low internal heat generation. Under high-speed and high load conditions, it does not melt or lose powder due to high tread temperature. Suitable for long-term continuous operation in the manufacturing process of semiconductors and liquid crystal panels, with good wear resistance, high load and high-speed usage environment.

Number	Outer diameter (mm)	Width (mm)	Inner diameter (mm)	Single wheel load (kg)
YLD-100×40-45	100	40	45	800
YLD-180×60-80	180	60	80	1000
YLD-200×48-80	200	48	80	1000
YLD-200×48-100	200	48	100	1200
YLD-240×60-80	240	60	80	1000
YLD-250×85-110	250	85	110	1500
YLD-300×80-145	300	80	145	1500
YLD-380×110-155	380	110	155	1500
YLD-380×340-80	380	340	80	1000
YLD-400×100-210	400	100	210	2400
YLD-400×200-275	400	200	275	2500
YLD-400×150-280	400	150	280	2000
YLD-440×200-290	440	200	290	2500
YLD-500×298-200	500	298	200	2500
YLD-500×298-200	500	298	200	2500
