ATLET Forklift Wheels

Our ATLET specialized wheels are made from carefully selected Nordic environmental standard polyurethane materials, combined with precision manufactured wheel cores and structural designs. The product not only has excellent wear resistance and load-bearing capacity, but also maximizes low rolling resistance and ultra quiet performance. Its excellent shock absorption characteristics ensure the smoothness of forklift operation on complex ground, not only effectively protecting high-value storage floors, but also creating a quiet and comfortable working environment for operators, perfectly fitting ATLET forklift’s people-oriented design concept.

Driving Wheels

Number	Outer diameter (mm)	Width (mm)	Inner diameter (mm)	Single wheel load (kg)	Corresponding code	Image
YLD-230×90-65-AT	230	90	65	1500	118032	View
YLD-230×90-65-AT	230	90	65	1500	9548743	View
YLD-350×140-80-AT	350	140	80	1800	110954	View
YLD-250×105-80-AT	250	105	80	1800	103483	View
YLD-350×155-90-AT	350	155	90	2000	113251	View
YLD-230×70-65-AT	230	70	65	1500	108987	View
YLD-250×75-80-AT	250	75	80	1800	078120	View

Load-Bearing wheels

Number	Outer diameter (mm)	Width (mm)	Inner diameter (mm)	Single wheel load (kg)	Corresponding code	Image
YLD-245×128-35.5-AT	245	128	35.5	1000	053925	View
YLD-260×85-62-AT	260	85	62	1500	074639	View
YLD-230×105-45-AT	230	105	45	1200	146852	View
YLD-250×105-45-AT	250	105	45	1200	110956	View

Training Wheels

Number	Outer diameter (mm)	Width (mm)	Inner diameter (mm)	Single wheel load (kg)	Corresponding code	Image
YLD-140×50-20-AT	140	50	20	600	109974	View
YLD-150×54-20-AT	150	54	20	600	060477	View

Rollers

Number	Outer diameter (mm)	Width (mm)	Inner diameter (mm)	Single wheel load (kg)	Corresponding code	Image
YLD-85×95-20-AT	85	95	20	600	060478	View
YLD-85×70/75-20-AT	85	70/75	20	600	100860	View

Attention: The above parameters are for reference only, and the actual model specifications and parameters shall prevail!
