HANGCHA Forklift Wheels

Our Hangcha special wheels are made of selected high toughness polyurethane material, combined with advanced casting technology, which enables the wheels to have ultra-high load-bearing capacity while maintaining excellent elasticity and cushioning performance. It not only has a much higher wear resistance than ordinary rubber wheels, but can easily cope with the wear of rough surfaces and frequent turning. It can also effectively prevent indentation on smooth indoor floors (such as warehouses, workshops, logistics centers), achieving smooth and quiet green operations.

We ensure that every product is accurately matched with the original specifications of Hangcha, easy to install, and has stable performance. Choosing our polyurethane wheels means giving your Hangcha forklift a longer service life, lower maintenance costs, and higher work efficiency, making it a wise choice for you to achieve cost reduction and efficiency improvement.

Driving Wheels

Number	Outer diameter (mm)	Width (mm)	Inner diameter (mm)	Single wheel load (kg)	Image
YLD-210×70/83-132-H	210	70/83	132	1600	View
YLD-210×70-83-H	210	70	83	2000	View
YLD-230×75-45-H	230	75	45	1500	View
YLD-230×75/82-45-H	230	75/82	45	1600	View
YLD-230×68-45-H	230	68	45	1400	View
YLD-230×75-82-H	230	75	82	2000	View
YLD-230×75-82-H	230	75	82	1500	View
YLD-250×80/87.5-45-H	250	80/87.5	45	1800	View
YLD-250×100-70-H	250	100	70	1600	View
YLD-250×100-80-H	250	100	80	1500	View
YLD-250×85-190-H	250	85	190	2000	View
YLD-343×114-80-H	343	114	80	1500	View
YLD-343×140-80-H	343	140	80	2000	View
YLD-343×135-80-H	343	135	80	1000	View
YLD-343×108-68-H	343	108	68	1500	View
YLD-380×122/132-132-H	380	122/132	132	2000	View

Load-Bearing wheels

Number	Outer diameter (mm)	Width (mm)	Inner diameter (mm)	Single wheel load (kg)	Image
YLD-200×100-110-H	200	100	110	1500	View
YLD-250×100-80-H	250	100	80	2000	View
YLD-250×120-68-H	250	120	68	1600	View
YLD-250×100-68-H	250	100	68	1500	View
YLD-254×71-80-H	254	71	80	1600	View
YLD-285×100-68-H	285	100	68	1400	View
YLD-285×120-107-H	285	120	107	1600	View

Training Wheels

Number	Outer diameter (mm)	Width (mm)	Inner diameter (mm)	Single wheel load (kg)	Image
YLD-100×70/72-19-H	100	70/72	19	900	View
YLD-100×40-25-H	100	40	25	1300	View
YLD-125×50-13-H	125	50	13	600	View
YLD-125×50-25-H	125	50	25	800	View
YLD-125×50-52-H	125	50	52		View
YLD-130×55/60-25-H	130	55/60	25	800	View
YLD-140×55-25-H	140	55	25	1200	View

Rollers

Number	Outer diameter (mm)	Width (mm)	Inner diameter (mm)	Single wheel load (kg)	Image
YLD-80×64/67-12-H	80	64/67	12	800	View
YLD-70×40-20-H	70	40	20	800	View
YLD-80×70-20-H	80	70	20	900	View
YLD-85×85-25-H	85	85	25	900	View
YLD-85×70-25-H	85	70	25	900	View
YLD-85×70/75-12-H	85	70/75	12	800	View
YLD-85×110-22-H	85	110	22	1200	View
YLD-85×100-55-H	85	100	55	900	View
YLD-85×85-16.5-H	85	85	16.5	800	View

Attention: The above parameters are for reference only, and the actual model specifications and parameters shall prevail!
