STILL Forklift Wheels

The STILL special wheels we produce are carefully selected from imported polyurethane raw materials and high-strength steel wheel cores, which are formed through precision coating technology. The product not only has extremely high wear resistance and tear resistance, but also can easily handle high-intensity, multi shift demanding operations. With its excellent elasticity and uniform hardness distribution, it achieves ultra quiet operation and thorough traceless protection, especially suitable for use in places with strict environmental requirements such as clean warehouses, food cold chains, and high-value logistics centers.

We ensure that every product is accurately benchmarked against STILL’s original factory technical parameters, achieving seamless installation and perfect performance fit. Choosing our polyurethane wheels is a value enhancement for your STILL forklift as an efficient asset, helping you move more steadily, statically, and efficiently on the path of pursuing excellent operations.

Driving Wheels

Number	Outer diameter (mm)	Width (mm)	Inner diameter (mm)	Single wheel load (kg)	Corresponding code	Image
YLD-211×70-45-S	211	70	45	1500		View
YLD-230×75-45-S	230	75	45	1500	0009933848	View
YLD-230×70-45-S	230	70	45	1500	4400716	View
YLD-230×75-45-S	230	75	45	1500	452304100	View
YLD-230×75-45-S	230	75	45	1500	50983508934	View
YLD-230×75-45-S	230	75	45	1500	4494553	View
YLD-230×75-80-S	230	75	80	1800	95309172	View
YLD-230×75-80-S	230	75	80	1800	452304100	View
YLD-250×100-80-S	250	100	80	1800	4494268	View
YLD-250×100-80-S	250	100	80	1800	4493241	View
YLD-250×82-80-S	250	82	80	1800	8305061	View
YLD-250×82-80-S	250	82	80	1800	4494575	View
YLD-252×100-80-S	252	100	80	1800	8428367	View
YLD-310×102-60-S	310	102	60	1600	8427484	View
YLD-310×112-60-S	310	112	60	1500	8428131	View
YLD-313×125-80-S	313	125	80	1800	8423414(6891392)	View
YLD-343×136-80-S	343	136	80	2000	328411	View
YLD-343×136-90-S	343	136	90	2000	365234	View
YLD-360×130-90-S	360	130	90	2000	8428189	View
YLD-360×140-90-S	360	140	90	2000	8428187	View
YLD-360×130-90-S	360	130	90	2000	12557928	View
YLD-360×140-90-S	360	140	90	2000	19712983	View
YLD-360×140-90-S	360	140	90	2000	11811864	View
YLD-360×130-90-S	360	130	90	2000	8437636	View
YLD-400×140-80-S	400	140	80	1800	8428770	View
YLD-406×170-110-S	406	170	110	2000	8435086	View
YLD-406×170-110-S	406	170	110	2000	38748706	View
YLD-406×170-110-S	406	170	110	2000	8686274	View
YLD-406×170-110-S	406	170	110	2000	8437635	View
YLD-406×170-110-S	406	170	110	2000	8435086	View

Load-Bearing wheels

Number	Outer diameter (mm)	Width (mm)	Inner diameter (mm)	Single wheel load (kg)	Corresponding code	Image
YLD-200×40-35-S	200	40	35	1200	8338633	View
YLD-200×80-36-S	200	80	36	1000	4464160	View
YLD-285×100-90-S	285	100	90	2000	9903910	View
YLD-310×102-90-S	310	102	90	2000	8365302	View
YLD-310×112-90-S	310	112	90	2000	8428131	View
YLD-350×100-40-S	350	100	40	2000	0009903911	View
YLD-350×100-78-S	350	100	78	2000	0009903916	View
YLD-350×100-78-S	350	100	78	2000	0029902330	View
YLD-370×160-60-S	370	160	60	2000	8429648	View
YLD-370×160-60-S	370	160	60	2000	8429655	View

Training Wheels

Number	Outer diameter (mm)	Width (mm)	Inner diameter (mm)	Single wheel load (kg)	Corresponding code	Image
YLD-125×50/61-16.5-S	125	50/61	16.5	500	459710	View
YLD-125×40-15-S	125	40	15	450	4401471	View
YLD-125×40-15-S	125	40	15	450	4493413	View
YLD-125×40-15-S	125	40	15	450	39903563	View
YLD-140×60-20-S	140	60	20	600	45239901	View
YLD-140×50-20-S	140	50	20	600	0009933922	View
YLD-140×50-20-S	140	50	20	600	39933811	View
YLD-140×54-20-S	140	54	20	600	4499771	View
YLD-140×54-20-S	140	54	20	600	4401514	View
YLD-140×54-20-S	140	54	20	600	50024505511	View
YLD-140×60-12-S	140	60	12	400	5008312	View
YLD-150×54/60-20-S	150	54/60	20	600	0009933402	View
YLD-150×54/60-20-S	150	54/60	20	600	4412343	View
YLD-150×54/60-20-S	150	54/60	20	600	4492271	View
YLD-150×48-20-S	150	48	20	600	3794505500	View
YLD-150×54-20-S	150	54	20	600	4414979	View
YLD-155×40-20-S	155	40	20	600	8428366	View
YLD-180×65-25-S	180	65	25	750	8665678	View
YLD-180×65-25-S	180	65	25	750	0009903802	View

Rollers

Number	Outer diameter (mm)	Width (mm)	Inner diameter (mm)	Single wheel load (kg)	Corresponding code	Image
YLD-80×100-12-S	80	100	12	500	4401475	View
YLD-85×100-25-S	85	100	25	600	4490050	View
YLD-85×90-12-S	85	90	12	500	9903501	View
YLD-85×90-12-S	85	90	12	500	9903545	View
YLD-85×105/110-12-S	85	105/110	12	500	4401476	View
YLD-85×60/65-12-S	85	60/65	12	500	8667979	View
YLD-85×80-12-S	85	80	12	500	8427733	View
YLD-85×80-17-S	85	80	17	500	0411624	View
YLD-85×80-20-S	85	80	20	600	8665538	View
YLD-85×100-20-S	85	100	20	600	8413923	View
YLD-85×65-17-S	85	65	17	500	4494719	View
YLD-85×60-17-S	85	60	17	500	8190118	View
YLD-85×80-17-S	85	80	17	500	0172656	View
YLD-100×40-32-S	100	40	32	700	0009933756	View

Attention: The above parameters are for reference only, and the actual model specifications and parameters shall prevail!
