WICKE Forklift Wheels

The WICKE special wheels we produce are made of highly tear resistant polyurethane formula and high-strength metal wheel cores, manufactured through precision processes. The product not only has excellent load-bearing capacity and wear resistance far beyond ordinary rubber wheels, but also can easily cope with the wear challenges of high-intensity operations. With its uniform hardness distribution and excellent buffering performance, it ensures the smooth, precise and low-noise operation of forklifts, effectively protecting the storage floor and improving operational comfort.

We ensure that every product is accurately matched with the original technical specifications of WICKE forklifts, achieving seamless installation and long-lasting reliable performance output. Choosing our polyurethane wheels gives your efficient WICKE forklift a longer service life and more stable ground performance, helping you achieve higher operational value in lean logistics operations.

Driving Wheels

Number	Outer diameter (mm)	Width (mm)	Inner diameter (mm)	Single wheel load (kg)	Corresponding code	Image
YLD-215×70-45-W	215	70	45	1000	156385	View
YLD-215×70-60-W	215	70	60	1200	171055	View
YLD-230×70-45-W	230	70	45	1000	154420	View
YLD-230×70-45-W	230	70	45	1000	164949	View
YLD-230×70-60-W	230	70	60	1200	225336	View
YLD-230×70-60-W	230	70	60	1200	230218	View
YLD-230×75-45-W	230	75	45	1000	122335	View
YLD-230×75-60-W	230	75	60	1200	183356	View
YLD-230×75-60-W	230	75	60	1200	250138	View
YLD-230×82-45-W	230	82	45	1000	157132	View
YLD-230×82-60-W	230	82	60	1200	195503	View
YLD-230×90-80-W	230	90	80	1500	209362	View
YLD-230×90-80-W	230	90	80	1500	156387	View
YLD-230×90-80-W	230	90	80	1500	216685	View
YLD-230×90-80-W	230	90	80	1500	219116	View
YLD-230×90-80-W	230	90	80	1500	232512	View
YLD-250×190-60-W	250	190	60	1200	184049	View
YLD-250×75-80-W	250	75	80	1500	148592	View
YLD-250×75-80-W	250	75	80	1500	156391	View
YLD-250×75-80-W	250	75	80	1500	168747	View
YLD-250×75-80-W	250	75	80	1500	182670	View
YLD-250×75-80-W	250	75	80	1500	228865	View
YLD-250×75-80-W	250	75	80	1500	232591	View
YLD-250×92-90-W	250	92	90	1500	225495	View
YLD-252×100-80-W	252	100	80	1500	169945	View
YLD-252×82-163-W	252	82	163	2000	154005	View
YLD-252×82-175-W	252	82	175	2000	195505	View
YLD-254×85/98-30-W	254	85/98	30	2000	168771	View
YLD-254×85/98-30-W	254	85/98	30	2000	195594	View
YLD-254×102-90-W	254	102	90	2000	241974	View
YLD-254×102-100-W	254	102	100	2000	248620	View
YLD-254×90-80-W	254	90	80	2000	185630	View
YLD-254×90-80-W	254	90	80	2000	199840	View
YLD-310×100-80-W	310	100	80	2000	247733	View
YLD-310×120-80-W	310	120	80	2000	220400	View
YLD-313×125-80-W	313	125	80	2000	190042	View
YLD-330×275–W	330	275		2200	213347	View
YLD-343×114-80-W	343	114	80	2000	156268	View
YLD-343×114-80-W	343	114	80	2000	190385	View
YLD-343×114-80-W	343	114	80	2000	191224	View
YLD-343×114-80-W	343	114	80	2000	195609	View
YLD-343×114-80-W	343	114	80	2000	197151	View
YLD-343×114-80-W	343	114	80	2000	197774	View
YLD-343×114-80-W	343	114	80	2000	208845	View
YLD-343×114-80-W	343	114	80	2000	227140	View
YLD-343×135-80-W	343	135	80	2000	197910	View
YLD-343×136-80-W	343	136	80	2000	168332	View
YLD-343×140-80-W	343	140	80	2000	156262	View
YLD-343×140-80-W	343	140	80	2000	227404	View
YLD-350×127.5-80-W	350	127.5	80	2000	174007	View
YLD-350×140-80-W	350	140	80	2000	204796	View
YLD-350×140-80-W	350	140	80	2000	243467	View
YLD-360×130-80-W	360	130	80	2000	201189	View
YLD-360×140-80-W	360	140	80	2000	202758	View
YLD-400×160-110-W	400	160	110	2500	196877	View
YLD-400×160-110-W	400	160	110	2500	206637	View
YLD-400×160-110-W	400	160	110	2500	212557	View
YLD-400×160-110-W	400	160	110	2500	212558	View
YLD-400×160-110-W	400	160	110	2500	247740	View
YLD-406×350-110-W	406	350	110	2500	242009	View

Load-Bearing wheels

Number	Outer diameter (mm)	Width (mm)	Inner diameter (mm)	Single wheel load (kg)	Corresponding code	Image
YLD-285×100-68-W	285	100	68	1500	198800	View
YLD-285×100-68-W	285	100	68	1500	208753	View
YLD-285×100-68-W	285	100	68	1500	212879	View
YLD-285×100-68-W	285	100	68	1500	235685	View
YLD-285×100-68-W	285	100	68	1500	237069	View
YLD-285×100-68-W	285	100	68	1500	234460	View
YLD-285×100-68-W	285	100	68	1500	250067	View
YLD-285×100-68-W	285	100	68	1500	255002	View
YLD-300×106-73-W	300	106	73	1800	235593	View
YLD-310×102-40-W	310	102	40	1200	206186	View
YLD-310×102-40-W	310	102	40	1200	224498	View
YLD-310×102-40-W	310	102	40	1200	216764	View
YLD-343×146-40-W	343	146	40	1200	201386	View
YLD-350×100-78-W	350	100	78	1800	237956	View
YLD-350×100-78-W	350	100	78	1800	244538	View
YLD-350×106-78-W	350	106	78	1800	222981	View
YLD-350×106-80-W	350	106	80	2000	228290	View
YLD-350×106-80-W	350	106	80	2000	251015	View
YLD-355×106-80-W	355	106	80	2000	224622	View

Training Wheels

Number	Outer diameter (mm)	Width (mm)	Inner diameter (mm)	Single wheel load (kg)	Corresponding code	Image
YLD-170×50/61-20-W	170	50/61	20	800	170429	View
YLD-150×130-25-W	150	130	25	800	252297	View
YLD-150×50-25-W	150	50	25	800	100868	View
YLD-150×50-25-W	150	50	25	800	117057	View
YLD-150×50-20-W	150	50	20	800	158090	View
YLD-150×50-17-W	150	50	17	600	184185	View
YLD-150×54-17-W	150	54	20	600	400299	View
YLD-150×54-20-W	150	54	20	800	168710	View
YLD-155×40-20-W	155	40	20	800	180645	View
YLD-230×110/115-30-W	230	110/115	30	1000	P400804	View
YLD-230×85-25-W	230	85	25	800	236299	View
YLD-125×50/61-16.5-W	125	50/61	16.5	500	145174	View
YLD-150×48/65-12-W	150	48/65	12	500	147318	View
YLD-150×54/60-20-W	150	54/60	20	600	143628	View
YLD-150×54/60-20-W	150	54/60	20	600	183163	View
YLD-150×78-12-W	150	78	12	500	217210	View
YLD-150×48-12-W	150	48	12	500	145300	View
YLD-90×50-20-W	90	50	20	600	146802	View
YLD-140×50-25-W	140	50	25	700	241963	View
YLD-140×50-25-W	140	50	25	700	241964	View
YLD-140×60-25-W	140	60	25	700	174906	View
YLD-100×40-20-W	100	40	20	600	114398	View
YLD-100×40-20-W	100	40	20	600	168553	View
YLD-100×40-20-W	100	40	20	600	223284	View
YLD-125×50-25-W	125	50	25	700	195157	View
YLD-125×50-25-W	125	50	25	700	194398	View
YLD-125×50-25-W	125	50	25	700	199316	View
YLD-125×50-25-W	125	50	25	700	202527	View
YLD-125×50-25-W	125	50	25	700	211442	View
YLD-125×50-25-W	125	50	25	700	218655	View
YLD-125×50-25-W	125	50	25	700	P400601	View
YLD-125×54-20-W	125	54	20	600	211845	View
YLD-125×54-20-W	125	54	20	600	214127	View
YLD-125×54-20-W	125	54	20	600	175503	View
YLD-125×60-20-W	125	60	20	600	224117	View
YLD-125×60-20-W	125	60	20	600	241970	View
YLD-125×60-20-W	125	60	20	600	241972	View
YLD-125×60-20-W	125	60	20	600	245401	View
YLD-140×50-20-W	140	50	20	600	164764	View
YLD-140×50-20-W	140	50	20	600	241965	View
YLD-140×54-20-W	140	54	20	600	157119	View
YLD-140×54-20-W	140	54	20	600	176698	View
YLD-140×54-20-W	140	54	20	600	206339	View
YLD-140×54-20-W	140	54	20	600	224685	View
YLD-140×54-20-W	140	54	20	600	228728	View
YLD-150×48-12-W	150	48	12	500	222053	View
YLD-150×54-20-W	150	54	20	600	400299	View
YLD-150×54-20-W	150	54	20	600	400466	View
YLD-180×65-20-W	180	65	20	600	164081	View
YLD-180×65-20-W	180	65	20	600	199572	View
YLD-140×54-20-W	140	54	20	600	198730	View

Rollers

Number	Outer diameter (mm)	Width (mm)	Inner diameter (mm)	Single wheel load (kg)	Corresponding code	Image
YLD-82×110-12-W	82	110	12	500	180875	View
YLD-82×82-12-W	82	82	12	500	171869	View
YLD-82×100-12-W	82	100	12	500	158256	View
YLD-82×100-12-W	82	100	12	500	171871	View
YLD-82×70-12-W	82	70	12	500	400269	View
YLD-82×82-12-W	82	82	12	500	202242	View
YLD-85×100-20-W	85	100	20	600	199417	View
YLD-85×100-20-W	85	100	20	600	400163	View
YLD-85×105-20-W	85	105	20	600	169393	View
YLD-85×110-20-W	85	110	20	600	155328	View
YLD-85×110-20-W	85	110	20	600	266959	View
YLD-85×110-20-W	85	110	20	600	195190	View
YLD-85×110-20-W	85	110	20	600	198961	View
YLD-85×60-12-W	85	60	12	500	127722	View
YLD-85×75-12-W	85	75	12	500	195195	View
YLD-85×85-12-W	85	85	12	500	152802	View
YLD-85×85-12-W	85	85	12	500	152099	View
YLD-85×85-12-W	85	85	12	500	195193	View
YLD-85×85-12-W	85	85	12	500	204250	View
YLD-85×85-12-W	85	85	12	500	206645	View
YLD-85×90-12-W	85	90	12	500	175885	View
YLD-85×90-12-W	85	90	12	500	192328	View
YLD-85×95-25-W	85	95	25	800	162854	View
YLD-85×95-25-W	85	95	25	800	195192	View
YLD-85×95-25-W	85	95	25	800	198105	View
YLD-85×95-25-W	85	95	25	800	208484	View
YLD-85×95-25-W	85	95	25	800	210104	View
YLD-85×95-25-W	85	95	25	800	242265	View
YLD-85×98-25-W	85	98	25	800	175886	View
YLD-85×90-12-W	85	90	12	500	171743	View
YLD-100×40-32-W	100	40	32	900	142443	View
YLD-82×64-20-W	82	64	20	800	104057	View
YLD-82×96-20-W	82	96	20	800	115430	View
YLD-82×96-20-W	82	96	20	800	170607	View
YLD-82×34-12-W	82	34	12	500	173226	View
YLD-82×75-12-W	82	75	12	500	176129	View
YLD-85×105-12-W	85	105	12	500	136861	View
YLD-85×105-12-W	85	105	12	500	206641	View
YLD-85×60/65-12-W	85	60/65	12	500	136863	View
YLD-85×60/65-12-W	85	60/65	12	500	168016	View
YLD-85×70/75-20-W	85	70/75	20	600	131922	View
YLD-85×80-12-W	85	80	12	500	136859	View
YLD-85×80-12-W	85	80	12	500	206640	View
YLD-85×80-17-W	85	80	17	500	131315	View
YLD-85×80-20-W	85	80	20	600	127723	View
YLD-85×100-20-W	85	100	20	600	400035	View
YLD-85×100-20-W	85	100	20	600	P400775	View
YLD-85×70-12-W	85	70	12	500	172621	View
YLD-85×70-20-W	85	70	20	600	195980	View
YLD-85×75-22-W	85	75	22	600	139130	View
YLD-85×75-22-W	85	75	22	600	140908	View
YLD-85×75-22-W	85	75	22	600	208516	View
YLD-85×75-22-W	85	75	22	600	P400586	View
YLD-85×74-12-W	85	74	12	500	235956	View
YLD-85×74-12-W	85	74	12	500	400039	View

Attention: The above parameters are for reference only, and the actual model specifications and parameters shall prevail!
