Xilin Forklift Wheels

Our production of specialized wheels for Xilin forklifts,Adopting high-quality polyurethane formula and sturdy wheel core structure, it combines excellent load-bearing capacity and outstanding wear resistance. Its wear resistance life far exceeds that of ordinary rubber wheels, and it can effectively cope with harsh environments such as metal debris and rough ground in the field, significantly reducing replacement frequency and maintenance costs. Meanwhile, the moderate hardness of the wheels provides excellent shock absorption, ensuring smooth operation of the forklift in various road conditions and effectively protecting the indoor floor from damage.

Driving Wheels:

Number	Outer diameter (mm)	Wheel width (mm)	Inner diameter (mm)	Load-bearing(kg)	Image
TLD-406×152-80-Xi	406	152	80	2000	View
TLD-280×100-80-Xi	406	152	80	1500	View
TLD-195×70-Xi	195	70	60	1500	View
TLD-250×80/114-Xi	250	80/114	182/65	1600	View
TLD-250×70-Xi	250	70	76	1500	View

Carrying wheel:

Number	Outer diameter (mm)	Wheel width (mm)	Inner diameter (mm)	Load-bearing(kg)	Image
TLD-210×85-120-Xi	210	85	120	1800	View
TLD-280×110-100-Xi	280	110	100	1000	View
TLD-150×82-80-Xi	150	82	80	1200	View
TLD-200×100-130-Xi	200	100	130	1600	View
TLD-250×80/92-120/107-Xi	250	80/92	120/107	1800	View
TLD-340×104-72-Xi	340	104	72	2000	View

Auxiliary wheel:

Number	diameter (mm)	Wheel width (mm)	Inner diameter (mm)	Load-bearing(kg)	Image
TLD-127×38-38/40-Xi	127	38	38/40	800	View
TLD-160×55-60-Xi	160	55	60	900	View
TLD-127×60-40-Xi	127	60	40	900	View
TLD-150×62-47-Xi	150	60	47	1200	View
TLD-127×57/60-40/17-Xi	127	57/60	40/17	900	View

Roller:

Number	Outer diameter (mm)	Wheel width (mm)	Inner diameter (mm)	Load-bearing(kg)	Image
TLD-82×126-52-Xi	82	126	52	800	View
TLD-80×70-47-Xi	80	70	47	800	View
TLD-80×84-47-Xi	80	84	47	800	View
TLD-60×30-15-Xi	60	30	35	500	View

Attention: The above parameters are for reference only, and the actual model specifications and parameters shall prevail!
