YALE Forklift Wheels

The YALE special wheels we produce are carefully selected from high wear-resistant polyurethane composite materials and reinforced wheel core structures, endowing the product with excellent load capacity and durability far beyond conventional rubber wheels. It can not only easily cope with the severe wear and tear test of high-frequency operations such as distribution centers and manufacturing, but also ensure the ultimate smoothness, low noise and no trace of driving with its optimized grounding area and uniform hardness distribution, effectively protecting the storage floor and improving operational comfort.

We strictly follow the original technical specifications of YALE forklifts to ensure precise matching and seamless integration of products in terms of size, rated load, and installation interface. Choosing our polyurethane wheels gives your trusted YALE forklift a longer service life, lower comprehensive maintenance costs, and superior ground adaptability, becoming a reliable guarantee for improving material handling efficiency.

Driving Wheels

Number	Outer diameter (mm)	Width (mm)	Inner diameter (mm)	Single wheel load (kg)	Corresponding code	Image
YLD-230×75-30-YA	230	75	30	1000	580013479	View
YLD-230×75-30-YA	230	75	30	1000	580041174	View
YLD-254×90-40-YA	254	90	40	1000	580052985	View
YLD-343×140-80-YA	343	140	80	1500	580075623	View
YLD-343×140-80-YA	343	140	80	1500	580060296	View
YLD-343×140-80-YA	343	140	80	1500	580026043	View
YLD-406×178-110-YA	406	178	110	2000	277218600	View

Load-Bearing wheels

Number	Outer diameter (mm)	Width (mm)	Inner diameter (mm)	Single wheel load (kg)	Corresponding code	Image
YLD-125×85-50-YA	125	85	50	1000	580062232	View
YLD-125×85-50-YA	125	85	50	1000	580062231	View
YLD-285×100-80-YA	285	100	80	1500	580026052	View
YLD-285×100-40-YA	285	100	40	1000	550044345	View
YLD-285×100-70-YA	285	100	70	1500	550044346	View
YLD-285×100-40-YA	285	100	40	1000	550044347	View

Training Wheels

Number	Outer diameter (mm)	Width (mm)	Inner diameter (mm)	Single wheel load (kg)	Corresponding code	Image
YLD-100×38-15-YA	100	38	15	500	582028466	View
YLD-125×50-25-YA	125	50	25	700	580062231	View
YLD-125×90-25-YA	125	90	25	700	580035669	View

Rollers

Number	Outer diameter (mm)	Width (mm)	Inner diameter (mm)	Single wheel load (kg)	Corresponding code	Image
YLD-84×90-10-YA	84	90	10	500	580037613	View
YLD-85×66-17-YA	85	66	17	500	580038706	View
YLD-85×98-20-YA	85	98	20	600	580038707	View
YLD-85×110-17-YA	85	110	17	500	582032968	View
YLD-85×95-12-YA	85	95	12	500	582015705	View
YLD-85×110-10-YA	85	110	10	600	580064668	View
YLD-85×70-20-YA	85	70	20	600	580037612	View
YLD-85×90-17-YA	85	90	17	500	580059476	View

Attention: The above parameters are for reference only, and the actual model specifications and parameters shall prevail!
